slim
Installing it is as easy as laying it down. The effect is practical and light. Only touch will reveal the small perimeter edge. Elegance and functionality in the kitchen.
satin
9609012821 satin-finished F3"slim
| basis | mm 500 |
| built-in fitting hole | mm 430 x 480 |
| bowl depth | mm 190 |
| square automatic pop - up waste kit with square control | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
012822 satin-finished F3" slim
| basis | mm 600 |
| built-in fitting hole | mm 550 x 480 |
| bowl depth | mm 190 |
| square automatic pop - up waste kit with square control | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
012823 satin-finished F3"slim
| basis | mm 800 |
| built-in fitting hole | mm 750 x 480 |
| bowl depth | mm 190 |
| square automatic pop - up waste kit with square control | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
012824 satin-finished F3"slim
| basis | mm 900 |
| built-in fitting hole | mm 840 x 480 |
| bowl depth | mm 190 |
| square automatic pop - up waste kit with square control | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
012825 satin-finished F3"slim
| basis | mm 900 |
| built-in fitting hole | mm 855 x 480 |
| bowls depth | mm 190 |
| square pop-up waste with two square controls | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
012843 satin-finished F3"slim
| basis 1 | mm 450/mm 500 if at beginning of kitchen |
| basis 2 | mm 900 for lowen than 50 mm |
| built-in fitting hole | mm 840 x 480 |
| bowl depth | mm 230 |
| square automatic pop - up waste kit with square control | |
| right and left version | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
012846 satin-finished F3"slim
| basis 1 | mm 600 |
| basis 2 | mm 1200 for top lower than 50 mm |
| built-in fitting hole | mm 980 x 480 |
| bowl depth | mm 230 |
| square automatic pop - up waste kit with square control | |
| right and left version | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
012845 satin-finished F3" slim
| basis 1 | mm 800 |
| basis 2 | mm 1200 for top lower than 50 mm |
| built-in fitting hole | mm 980 x 480 |
| bowls depth | mm 230 - 130 |
| square automatic pop - up waste kit with square control | |
| the LEFT or RIGHT version refers to the position of the larger sink bowl. | |
| right and left version | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.4
092028
stainless steel perforated tray
mm 320 x 190
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
012849 satin-finished F3"slim
| basis 1 | mm 800 |
| basis 2 | mm 1200 for top lower than 50 mm |
| built-in fitting hole | mm 1140 x 480 |
| bowl depth | mm 230 |
| square automatic pop - up waste kit with square control | |
| right and left version | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
012847 satin-finished F3"slim
| basis 1 | mm 900 |
| basis 2 | mm 1200 for top lower than 50 mm |
| built-in fitting hole | mm 1140 x 480 |
| bowls depth | mm 230 |
| square pop-up waste with two square controls | |
| right and left version | |
technical
optionals
2.7
092041
stainless steel perforated bowl
mm 405 x 230
3.9
092040
stainless steel perforated tray
mm 400 x 400
4.8
093102
stainless steel basket
mm 340 x 350
7.2
094013
iroko and PE chopping board
mm 400 x 400
11.1
093004
stainless roll up carpet
mm 470x450
