slim
Installing it is as easy as laying it down. The effect is practical and light. Only touch will reveal the small perimeter edge. Elegance and functionality in the kitchen.
satin
microdecoro
9102015003 satin-finished F3" slim
015073 microdecoro F3" slim
| basis 1 | mm 450 / mm 500 if at beginning of kitchen |
| basis 2 | mm 900 for top lower than 30 mm |
| built-in fitting hole | mm 850 x 490 |
| filotop base | see diagram |
| bowl depth | mm 195 |
| reversible version | |
| Rondo' automatic pop -up waste kit with square control | |
technical
optionals
1.1
092000
withe ABS tray
mm 342 x 410
2.3
092031
stainless steel perforated bowl
mm 410 x 230
2.13
092065
stainless steel perforated bowl with draining rack
410x280 h.70
2.14
092066
stainless steel perforated bowl
410x280 h.70
4.4
093080
stainless steel basket
mm 400 x 325
5.6
094095
PE white chopping board
mm 420 x 320
5.7
094096
black HPL bowl covers
mm 250 x 415
5.9
094097
black HPL support grid
mm 250 x 415
5.10
094098
2 black HPL multipurpose bars
mm 50 x 415
5.11
092064
stainless steel perforated tray with HPL black cho
mm 410x280
6.6
094073
iroko chopping board
mm 330 x 390
11.1
093004
stainless roll up carpet
mm 470x450
015006 satin-finished F3" slim
015076 microdecoro F3" slim
| basis 1 | mm 600 / mm 800 if at beginning of kitchen |
| basis 2 | mm 1200 per piano inferiore 30 mm |
| built-in fitting hole | mm 990 x 490 |
| bowl depth | mm 205 |
| reversible version | |
| Rondo' automatic pop -up waste kit with square control | |
technical
optionals
1.1
092000
withe ABS tray
mm 342 x 410
2.3
092031
stainless steel perforated bowl
mm 410 x 230
2.13
092065
stainless steel perforated bowl with draining rack
410x280 h.70
2.14
092066
stainless steel perforated bowl
410x280 h.70
4.4
093080
stainless steel basket
mm 400 x 325
5.6
094095
PE white chopping board
mm 420 x 320
5.7
094096
black HPL bowl covers
mm 250 x 415
5.9
094097
black HPL support grid
mm 250 x 415
5.10
094098
2 black HPL multipurpose bars
mm 50 x 415
5.11
092064
stainless steel perforated tray with HPL black cho
mm 410x280
6.6
094073
iroko chopping board
mm 330 x 390
11.1
093004
stainless roll up carpet
mm 470x450
015005 satin-finished F3" slim
015075 microdecoro F3" slim
| basis 1 | mm 800 |
| basis 2 | mm 1200 per piano inferiore 30 mm |
| built-in fitting hole | mm 990 x 490 |
| bowls depth | mm 195 - 130 |
| reversible version | |
| the LEFT or RIGHT version refers to the position of the larger sink bowl. | |
| Rondo' automatic pop -up waste kit with square control | |
technical
optionals
1.1
092000
withe ABS tray
mm 342 x 410
2.1
092020
stainless steel perforated bowl
mm 335 x 145
2.3
092031
stainless steel perforated bowl
mm 410 x 230
2.13
092065
stainless steel perforated bowl with draining rack
410x280 h.70
2.14
092066
stainless steel perforated bowl
410x280 h.70
4.4
093080
stainless steel basket
mm 400 x 325
5.6
094095
PE white chopping board
mm 420 x 320
5.7
094096
black HPL bowl covers
mm 250 x 415
5.9
094097
black HPL support grid
mm 250 x 415
5.10
094098
2 black HPL multipurpose bars
mm 50 x 415
5.11
092064
stainless steel perforated tray with HPL black cho
mm 410x280
6.6
094073
iroko chopping board
mm 330 x 390
11.1
093004
stainless roll up carpet
mm 470x450
015007 satin-finished F3" slim
015077 microdecoro F3" slim
| basis 1 | mm 900 |
| basis 2 | mm 1200 per piano inferiore 30 mm |
| built-in fitting hole | mm 1150 x 490 |
| bowls depth | mm 195 |
| reversible version | |
| Rondo' automatic pop -up waste kit with square control | |
technical
optionals
1.1
092000
withe ABS tray
mm 342 x 410
2.3
092031
stainless steel perforated bowl
mm 410 x 230
2.13
092065
stainless steel perforated bowl with draining rack
410x280 h.70
2.14
092066
stainless steel perforated bowl
410x280 h.70
4.4
093080
stainless steel basket
mm 400 x 325
5.6
094095
PE white chopping board
mm 420 x 320
5.7
094096
black HPL bowl covers
mm 250 x 415
5.9
094097
black HPL support grid
mm 250 x 415
5.10
094098
2 black HPL multipurpose bars
mm 50 x 415
5.11
092064
stainless steel perforated tray with HPL black cho
mm 410x280
6.6
094073
iroko chopping board
mm 330 x 390
11.1
093004
stainless roll up carpet
mm 470x450
